System
|
|
Main Processor
|
Embedded Processor
|
|
Operating System
|
Embedded LINUX
|
|
Video and Audio
|
|
Analog Camera Input
|
4/8 Channel, BNC
|
|
HDCVI Camera
|
5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
|
|
AHD Camera
|
5MP, 4MP, 1080P@25/30, 720P@25/30fps
|
|
TVI Camera
|
5MP, 4MP, 1080P@25/30, 720P@25/30fps
|
|
CVBS Camera
|
PAL/NTSC
|
|
IP Camera Input
|
4+2/8+4CH, each channel up to 6MP
|
|
Audio In/Out
|
1/1, RCA
|
|
Two-way Talk
|
Reuse audio in/out, RCA
|
|
Recording
|
|
Video Compression
|
H.265+/H.265/H.264+/H.264
|
|
Resolution
|
5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
|
|
Record Rate
|
Main Stream:
4CH: the 1st channel 5M-N(1~10fps);
8CH: the 1st & 2nd channels 5M-N(1~10fps);
other channels 4M-N/1080P(1~15fps); 1080N/720P/960H/
D1/CIF (1~25/30fps)
Sub stream:
CIF/QCIF (1~15fps)
|
|
Video Bit Rate
|
32Kbps ~ 6144Kbps Per Channel
|
|
Record Mode
|
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
|
|
Record Interval
|
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
|
|
Audio Compression
|
AAC(only for the 1st channel), G.711A, G.711U, PCM
|
|
Audio Sample Rate
|
8KHz, 16 bit Per Channel
|
|
Audio Bit Rate
|
64Kbps Per Channel
|
|
Display
|
|
Interface
|
1 HDMI ,1 VGA
|
|
Resolution
|
1920×1080, 1280×1024, 1280×720
|
|
Multi-screen Display
|
When IP extension mode not enabled:
4CH: 1/4
8CH: 1/4/8/9
When IP extension mode enabled:
4CH: 1/4/6
8CH: 1/4/8/9/16
|
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
|
|
Network
|
|
Interface
|
1 RJ-45 Port (100M)
|
|
Network Function
|
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
|
|
Max. User Access
|
128 users
|
|
Smart Phone
|
iPhone, iPad, Android
|
|
Interoperability
|
ONVIF 16.12, CGI Conformant
|
