Support Intel® 10th/11th generation Core™ i3/i5/i7, Pentium®, Celeron®125W LGA1200 CPU
CHIPSET
Intel H570 express chipset
MEMORY
(4)DDR4 3200 (11th CPU only)MHz / 2933MHz / 2666MHz support, dual channel up to 128GB (32GB*4)
VIDEO OUTPUT
(1)HDMI + (2)DisplayPort support triple independent display 4K/60Hz playback (With Integrated Graphic in CPU)
AUDIO
Realtek ALC662/ALC897 5.1 Channel high definition audio
ETHERNET
Intel i210AT + i219 10Mb/s,100Mb/s,1Gb/s operation Support Wake-On-LAN function
STORAGE INTERFACE
SATA 6.0Gb/s interface
ONBOARD CONNECTORS
(2)4 Pin fan connector (4)SATA 6 connector (1) ATX main power (2*10) (1) ATX 12V power (2*2) (1) 1X4 USB 2.0 header (1) RS232 header (1) VGA header (1) Front AUDIO header (2) Front USB FFC header
FRONT PANEL
(3) USB 3.2 Gen 1 Port (1) USB 3.2 Gen 1 type-C Port (1) Microphone-In (1) SPK-Out (1) Power LED (1) HDD LED (1) Power-On button (1) Power-On button
BACK PANEL
(4) USB 2.0 Port (4) USB 3.2 Gen 2 Port (2)LAN (1)HDMI port (2)Display port (1)Audio Mic in (1)Audio Line in (1)Audio SPK out (1)Clear CMOS button (3)Antenna Hole
DRIVE BAYS
(1) 5.25" ODD bay (2) 3.5" HDD bay Support 2.5" HDD x2 or 4, if use accessory PHD3 x1 or 2
DIMENSIONS
332.1(L) x 215.2(W) x 190.1(H) mm
POWER
80 Plus 300W power supply Input: 100-240V，6-3A AC Support 80 PLUS Bronze
ACCESSORIES
XPC Multi-Language quick guide XPC DVD Driver SATA Cable CPU Thermal Grease Power cord Screw package
EXPANSION SLOT
(1) PCI-E X16 Gen 4.0 slot (1) PCI-E X4 Gen 3.0 slot (1) M.2 2280 type M key socket (1) M.2 2230 type E key socket
Support Intel® 10th/11th generation Core™ i3/i5/i7, Pentium®, Celeron®125W LGA1200 CPU
CHIPSET
Intel H570 express chipset
MEMORY
(4)DDR4 3200 (11th CPU only)MHz / 2933MHz / 2666MHz support, dual channel up to 128GB (32GB*4)
VIDEO OUTPUT
(1)HDMI + (2)DisplayPort support triple independent display 4K/60Hz playback (With Integrated Graphic in CPU)
AUDIO
Realtek ALC662/ALC897 5.1 Channel high definition audio
ETHERNET
Intel i210AT + i219 10Mb/s,100Mb/s,1Gb/s operation Support Wake-On-LAN function
STORAGE INTERFACE
SATA 6.0Gb/s interface
ONBOARD CONNECTORS
(2)4 Pin fan connector (4)SATA 6 connector (1) ATX main power (2*10) (1) ATX 12V power (2*2) (1) 1X4 USB 2.0 header (1) RS232 header (1) VGA header (1) Front AUDIO header (2) Front USB FFC header
FRONT PANEL
(3) USB 3.2 Gen 1 Port (1) USB 3.2 Gen 1 type-C Port (1) Microphone-In (1) SPK-Out (1) Power LED (1) HDD LED (1) Power-On button (1) Power-On button
BACK PANEL
(4) USB 2.0 Port (4) USB 3.2 Gen 2 Port (2)LAN (1)HDMI port (2)Display port (1)Audio Mic in (1)Audio Line in (1)Audio SPK out (1)Clear CMOS button (3)Antenna Hole
DRIVE BAYS
(1) 5.25" ODD bay (2) 3.5" HDD bay Support 2.5" HDD x2 or 4, if use accessory PHD3 x1 or 2
DIMENSIONS
332.1(L) x 215.2(W) x 190.1(H) mm
POWER
80 Plus 300W power supply Input: 100-240V，6-3A AC Support 80 PLUS Bronze
ACCESSORIES
XPC Multi-Language quick guide XPC DVD Driver SATA Cable CPU Thermal Grease Power cord Screw package
EXPANSION SLOT
(1) PCI-E X16 Gen 4.0 slot (1) PCI-E X4 Gen 3.0 slot (1) M.2 2280 type M key socket (1) M.2 2230 type E key socket
מערכת מחשב ברבון Shuttle XH510G2 ,
מערכת בגודל 5 ליטר , לחיסכון במקום, לוח עם ערכת שבבים H510 , התומך במעבדי אינטל מהדור ה 10 וה 11 , למרות מימדי המארז הקטן המערכת תומכת בחריצי הרחבה מסוג PCI-Ex16 slot להתקנת כרטיס מסך ,כרטיס לכידת ווידאו , או כרטיסים אחרים לפי דרשות המערכת, המחשב כולל בנוסף: 4x USB 3.2 Gen1, 4x USB 2.0, an HDMI 2.0, a DisplayPort 1.4, SATA connectors, M.2 slots, and Intel® Gigabit LAN , המחשב מתאים במיוחד לקירות ווידאו ,קופות רושמות , מערכות אבטחה ועוד video wall, POS server, surveillance, professional creators, and Kiosk applications.המערכת אינה כוללת מעבד , זיכרון דיסק קשיח ומערכת הפעלה אותם יש לרכוש בנפרד,
